Blum Aventos HF mechanism for bifold doors, 22F2800

The use of bi-folding doors in a kitchen creates a sophisticated & contemporary design statement. When coupled with the Blum Aventos HF lift mechanism this also adds the benefit of a high degree of practicality & functionality along with Blum's soft closing action.

Suitable for use with a range of door styles, they cover popular door & cabinet sizes. Suits external heights 480mm to 1200mm high and up to 1800mm in width.

Ideal for use with solid timber doors, MDF or MFC or even a combination of materials such as aluminium framed at the bottom and a solid door at the top.

Important: Blum Aventos HF system requires a minimum internal carcass depth of 264mm. Minimum internal 480mm Cabinet height up to 1200mm.

Power factor 10,000 to 19,300. Chipboard screws included for our customers. Five year warranty against manufacturing defects.

This sale is for the Mechanism only- Please order cover caps etc separately - See related products

The following is a helpful guide to parts that may be required also. See related products or below :

1. lift mechanism (This sale) X2 per set.
2. Cover caps
3. telescopic arms set
4. Pair of front fixing brackets
5. Servo drive for HF if required along with transformer & Kit

Mechanism information: Power Factor X Code Required

• 10,000 to 19,300 = 22F2800 Medium lift

 Features

• Blum Aventos HF mechanism
• Soft closing
• Blum quality
• For bi-folding doors
• Suits a range of materials
• Quick & easy fitting
• Can be adjusted for optimal function
• Minimum internal depth required 264mm
• Five year warranty

Technical (HELP) To obtain the correct power factor: Multiply cabinet height x Door weight including handle (Kg)

Set includes

• Mechanism only
• Screws

Need help? Call our helpful team on TEL 01205 760462 or see

Take a look at The Aventos HF Range HERE
